產品詳情
FEATURES AND APPLICATION/特性和用途
?Mnolithic construction yields high reliability | ?獨石結構，高可靠性 |
?High self-resonant frequency | ?高自諧振頻率 |
?Excellent solderability and heat resistance for either flow | ?良好的可焊性和耐焊性 |
?High frequency circuits of telecommunication | ?通訊產品的射頻模塊 |
?Mobile phones such as GSM, CDMA, PDC, etc. | ?GSM、CDMA、PDC手機 |
?"Bluetooth" | ?藍牙模塊 |
?Other High frequency circuits in general | ?其它高頻線路應用中 |
COIL MX | L(nH) | L Test Freq. | Q Min | SRF(MHz) | DCR(Ω) | Ir(mA) | ||
100 MHz | 800 MHz | 1800 MHz | ||||||
MCI0603H1N0□ | 1.0 | 100 | 4.0 | 12.0 | 19.0 | 12000 | 0.20 | 300 |
MCI0603H1N2□ | 1.2 | 100 | 4.0 | 12.0 | 18.0 | 11000 | 0.22 | 300 |
MCI0603H1N5□ | 1.5 | 100 | 4.0 | 12.0 | 18.0 | 11000 | 0.24 | 300 |
MCI0603H1N8□ | 1.8 | 100 | 4.0 | 11.0 | 17.0 | 10000 | 0.27 | 300 |
MCI0603H2N2□ | 2.2 | 100 | 4.0 | 12.0 | 19.0 | 10000 | 0.30 | 300 |
MCI0603H2N7□ | 2.7 | 100 | 4.0 | 13.0 | 19.0 | 10000 | 0.35 | 300 |
MCI0603H3N3□ | 3.3 | 100 | 4.0 | 13.0 | 19.0 | 10000 | 0.40 | 200 |
MCI0603H3N9□ | 3.9 | 100 | 4.0 | 13.0 | 19.0 | 9000 | 0.45 | 200 |
MCI0603H4N7□ | 4.7 | 100 | 5.0 | 13.0 | 19.0 | 8500 | 0.50 | 200 |
MCI0603H5N6□ | 5.6 | 100 | 5.0 | 12.0 | 18.0 | 8500 | 0.60 | 200 |
MGC0603H6N8□ | 6.8 | 100 | 5.0 | 13.0 | 19.0 | 6000 | 0.65 | 200 |
MCI0603H8N2□ | 8.2 | 100 | 5.0 | 13.0 | 19.0 | 6000 | 0.70 | 200 |
MCI0603H10N□ | 10 | 100 | 5.0 | 13.0 | 18.0 | 5500 | 0.80 | 200 |
MCI0603T12N□ | 12 | 100 | 5.0 | 12.0 | 18.0 | 5000 | 1.00 | 150 |
MCI0603T15N□ | 15 | 100 | 5.0 | 12.0 | 17.0 | 4500 | 1.10 | 150 |
MCI0603T18N□ | 18 | 100 | 5.0 | 12.0 | 16.0 | 4000 | 1.30 | 100 |
MCI0603T22N□ | 22 | 100 | 5.0 | 12.0 | 16.0 | 3500 | 1.60 | 100 |
MCI0603T27N□ | 27 | 100 | 5.0 | 12.0 | 15.0 | 3000 | 1.70 | 100 |
MCI0603T33N□ | 33 | 100 | 5.0 | 11.0 | 14.0 | 2800 | 1.80 | 100 |
COIL MX | L(nH) | L Test Freq. | Q Min | SRF(MHz) | DCR(Ω) | Ir(mA) | ||
100 MHz | 900 MHz | 1800 MHz | ||||||
MCI1005T1N0□ | 1.0 | 100 | 9 | 44 | 50 | 10000 | 0.08 | 400 |
MCI1005T1N2□ | 1.2 | 100 | 9 | 44 | 50 | 10000 | 0.08 | 400 |
MCI1005T1N5□ | 1.5 | 100 | 9 | 43 | 48 | 6000 | 0.10 | 400 |
MCI1005T1N8□ | 1.8 | 100 | 9 | 35 | 45 | 6000 | 0.12 | 400 |
MCI1005T2N2□ | 2.2 | 100 | 9 | 30 | 43 | 6000 | 0.12 | 400 |
MCI1005T2N4□ | 2.4 | 100 | 9 | 30 | 43 | 6000 | 0.12 | 400 |
MCI1005T2N7□ | 2.7 | 100 | 9 | 30 | 40 | 6000 | 0.13 | 400 |
MCI1005T3N0□ | 3.0 | 100 | 9 | 30 | 40 | 6000 | 0.15 | 400 |
MCI1005T3N3□ | 3.3 | 100 | 9 | 30 | 40 | 6000 | 0.15 | 400 |
MCI1005T3N9□ | 3.9 | 100 | 9 | 30 | 41 | 4500 | 0.21 | 400 |
MCI1005T4N3□ | 4.3 | 100 | 9 | 30 | 36 | 4500 | 0.21 | 300 |
MCI1005T4N7□ | 4.7 | 100 | 9 | 29 | 38 | 4500 | 0.21 | 300 |
MCI1005T5N6□ | 5.6 | 100 | 9 | 25 | 32 | 4000 | 0.23 | 300 |
MCI1005T6N8□ | 6.8 | 100 | 9 | 25 | 33 | 4000 | 0.25 | 300 |
MCI1005T8N2□ | 8.2 | 100 | 9 | 25 | 32 | 3600 | 0.35 | 300 |
MCI1005T9N1□ | 9.1 | 100 | 9 | 25 | 31 | 3200 | 0.42 | 300 |
MCI1005T10N□ | 10 | 100 | 9 | 26 | 30 | 3200 | 0.42 | 300 |
MCI1005T12N□ | 12 | 100 | 9 | 26 | 29 | 2800 | 0.50 | 300 |
MCI1005T15N□ | 15 | 100 | 9 | 25 | 26 | 2500 | 0.60 | 300 |
MCI1005T18N□ | 18 | 100 | 9 | 23 | 24 | 2200 | 0.80 | 300 |
MCI1005T22N□ | 22 | 100 | 9 | 23 | 22 | 1900 | 0.85 | 300 |
MCI1005T27N□ | 27 | 100 | 9 | 23 |
| 1600 | 1.00 | 300 |
MCI1005T33N□ | 33 | 100 | 9 | 22 |
| 1300 | 1.00 | 200 |
MCI1005T39N□ | 39 | 100 | 9 | 21 |
| 1200 | 1.30 | 200 |
MCI1005T47N□ | 47 | 100 | 9 | 20 |
| 1000 | 1.50 | 200 |
MCI1005T56N□ | 56 | 100 | 9 | 17 |
| 750 | 1.80 | 200 |
MCI1005T68N□ | 68 | 100 | 9 | 15 |
| 750 | 1.95 | 180 |
MCI1005T82N□ | 82 | 100 | 9 |
|
| 600 | 2.10 | 150 |
MCI1005TR10□ | 100 | 100 | 9 |
|
| 600 | 2.50 | 150 |
MCI1005TR12□ | 120 | 100 | 9 |
|
| 600 | 2.80 | 150 |
MCI1005TR15□ | 150 | 100 | 8 |
|
| 550 | 2.35 | 150 |
MCI1005TR18□ | 180 | 100 | 8 |
|
| 500 | 2.55 | 100 |
MCI1005TR22□ | 220 | 100 | 8 |
|
| 450 | 2.65 | 100 |
MCI1005TR27□ | 270 | 100 | 8 |
|
| 400 | 2.85 | 50 |
MCI1005TR33□ | 330 | 50 | 8 |
|
| 350 | 3.00 | 50 |
COIL MX | L (nH) | Q /min | L,Q Test Freq. | SRF(MHz) | RDC(Ω) | Ir(mA) |
MCI1608H1N0□ | 1.0 | 8 | 100 | >10000 | 0.05 | 500 |
MCI1608H1N2□ | 1.2 | 8 | 100 | >10000 | 0.05 | 500 |
MCI1608H1N5□ | 1.5 | 8 | 100 | >10000 | 0.10 | 500 |
MCI1608H1N8□ | 1.8 | 8 | 100 | >10000 | 0.10 | 500 |
MCI1608H2N2□ | 2.2 | 8 | 100 | 10000 | 0.10 | 500 |
MCI1608H2N7□ | 2.7 | 10 | 100 | 9000 | 0.10 | 500 |
MCI1608H3N3□ | 3.3 | 10 | 100 | 8000 | 0.12 | 500 |
MCI1608H3N9□ | 3.9 | 10 | 100 | 7000 | 0.14 | 500 |
MCI1608H4N7□ | 4.7 | 10 | 100 | 5500 | 0.16 | 500 |
MCI1608H5N6□ | 5.6 | 10 | 100 | 4500 | 0.18 | 500 |
MCI1608H6N8□ | 6.8 | 10 | 100 | 4000 | 0.22 | 500 |
MCI1608H8N2□ | 8.2 | 10 | 100 | 3600 | 0.24 | 500 |
MCI1608H10N□ | 10.0 | 12 | 100 | 3400 | 0.26 | 300 |
MCI1608H12N□ | 12.0 | 12 | 100 | 2800 | 0.30 | 300 |
MCI1608H15N□ | 15.0 | 12 | 100 | 2500 | 0.32 | 300 |
MCI1608H18N□ | 18.0 | 12 | 100 | 2100 | 0.35 | 300 |
MCI1608H22N□ | 22.0 | 12 | 100 | 1700 | 0.40 | 300 |
MCI1608H27N□ | 27.0 | 12 | 100 | 1500 | 0.45 | 300 |
MCI1608H33N□ | 33.0 | 12 | 100 | 1300 | 0.55 | 300 |
MCI1608H39N□ | 39.0 | 12 | 100 | 1100 | 0.60 | 300 |
MCI1608H47N□ | 47.0 | 12 | 100 | 1000 | 0.70 | 300 |
MCI1608H56N□ | 56.0 | 12 | 100 | 900 | 0.75 | 300 |
MCI1608H68N□ | 68.0 | 12 | 100 | 700 | 0.85 | 300 |
MCI1608H82N□ | 82.0 | 12 | 100 | 600 | 0.95 | 300 |
MCI1608HR10□ | 100.0 | 12 | 100 | 600 | 1.00 | 300 |
MCI1608HR12□ | 120.0 | 8 | 50 | 500 | 1.30 | 300 |
MCI1608HR15□ | 150.0 | 8 | 50 | 500 | 1.50 | 300 |
MCI1608HR18□ | 180.0 | 8 | 50 | 400 | 1.80 | 300 |
MCI1608HR22□ | 220.0 | 8 | 50 | 400 | 2.10 | 300 |
MCI1608HR27□ | 270.0 | 8 | 50 | 350 | 2.40 | 300 |
MCI1608HR33□ | 330 | 8 | 50 | 350 | 3.0 | 300 |
COIL MX | L (nH) | Q /min | L,Q Test Freq. | SRF(MHz) | RDC(Ω) | Ir(mA) |
MCI2012H1N5□ | 1.5 | 10 | 100 | 6000 | 0.10 | 600 |
MCI2012H1N8□ | 1.8 | 10 | 100 | 6000 | 0.10 | 600 |
MCI2012H2N2□ | 2.2 | 10 | 100 | 6000 | 0.10 | 600 |
MCI2012H2N7□ | 2.7 | 12 | 100 | 6000 | 0.10 | 600 |
MCI2012H3N3□ | 3.3 | 12 | 100 | 6000 | 0.13 | 600 |
MCI2012H3N9□ | 3.9 | 12 | 100 | 5000 | 0.15 | 600 |
MCI2012H4N7□ | 4.7 | 12 | 100 | 4000 | 0.20 | 400 |
MCI2012H5N6□ | 5.6 | 15 | 100 | 3500 | 0.23 | 400 |
MCI2012H6N8□ | 6.8 | 15 | 100 | 2800 | 0.25 | 400 |
MCI2012H8N2□ | 8.2 | 15 | 100 | 2400 | 0.28 | 400 |
MCI2012H10N□ | 10 | 15 | 100 | 2100 | 0.30 | 300 |
MCI2012H12N□ | 12 | 15 | 100 | 1900 | 0.35 | 300 |
MCI2012H15N□ | 15 | 15 | 100 | 1800 | 0.40 | 300 |
MCI2012H18N□ | 18 | 15 | 100 | 1500 | 0.45 | 300 |
MCI2012H22N□ | 22 | 15 | 100 | 1400 | 0.50 | 300 |
MCI2012H27N□ | 27 | 15 | 100 | 1300 | 0.55 | 300 |
MCI2012H33N□ | 33 | 15 | 100 | 1200 | 0.60 | 300 |
MCI2012H39N□ | 39 | 15 | 100 | 1000 | 0.65 | 300 |
MCI2012H47N□ | 47 | 15 | 100 | 900 | 0.70 | 300 |
MCI2012H56N□ | 56 | 15 | 100 | 800 | 0.75 | 300 |
MCI2012H68N□ | 68 | 15 | 100 | 700 | 0.80 | 300 |
MCI2012H82N□ | 82 | 15 | 100 | 600 | 0.90 | 300 |
MCI2012HR10□ | 100 | 15 | 100 | 600 | 0.90 | 300 |
MCI2012HR12□ | 120 | 13 | 100 | 500 | 0.95 | 300 |
MCI2012HR15□ | 150 | 13 | 50 | 500 | 1.00 | 300 |
MCI2012HR18□ | 180 | 13 | 50 | 400 | 1.20 | 300 |
MCI2012HR22□ | 220 | 12 | 50 | 350 | 1.40 | 300 |
MCI2012HR27□ | 270 | 12 | 50 | 300 | 1.70 | 300 |
MCI2012HR33□ | 330 | 12 | 50 | 250 | 2.00 | 300 |
MCI2012HR39□ | 390 | 10 | 50 | 250 | 2.50 | 300 |
MCI2012HR47□ | 470 | 10 | 50 | 200 | 2.80 | 300 |
